Face Mills
Cutter bodies are machined from through-hardened alloy steel with differential pitch to suppress resonance on long overhangs. Coolant is directed at each pocket rather than flooded across the face.
- Steel
- Stainless steel
- Cast iron
- Non-ferrous
- Superalloys & titanium
Why this range
- Ø40 – 250 mm, coarse through fine pitch
- Differential pitch for stable long-reach cuts
- Pocket-directed coolant channels as standard
At a glance
- Series
- VC-FM
- Family
- Milling
- ISO coverage
- Steel
- Stainless steel
- Cast iron
- Non-ferrous
- Superalloys & titanium
- Recommended grades
- VC1015VC2030VC3010
Specifications
| Parameter | Value |
|---|---|
| Cutting diameter | 40 – 250 mm |
| Insert size | SEKT / APKT / RDMT / ODMT |
| Depth of cut | up to 12 mm |
| Connection | Arbor, weldon, screw-in, PSC |
| Balance quality | G6.3 at 12,000 rpm |
| Coolant supply | Through-body to each pocket |
Applications
- Face milling
- Shoulder milling
- High-feed milling
- Roughing
ISO material coverage
Application windows this family is specified into. Grade selection narrows within them.
- P
Steel
Unalloyed to high-alloy steel, cast steel
- M
Stainless steel
Austenitic, ferritic, duplex and super duplex
- K
Cast iron
Grey, nodular, malleable and compacted graphite iron
- N
Non-ferrous
Aluminium, copper alloys, brass, plastics
- S
Superalloys & titanium
Nickel and cobalt alloys, titanium, tungsten alloys
Recommended grades
Grades released for this family, with their position on the toughness and wear-resistance axis.
VC1015
PMPVD TiAlN
- Toughness
- 72
- Wear resistance
- 58
VC2030
PKCVD TiCN-Al₂O₃
- Toughness
- 48
- Wear resistance
- 88
VC3010
SHPVD AlCrN
- Toughness
- 55
- Wear resistance
- 82
